 Logic Sample Program
 >Logitouch Editor >A day of the week-acquisition process

From the specified year, month, and day or date of the current day, a day of the week is calculated.


In Logitouch, the current year, month, and day can be read out with using the system variable, LS[4]-[6]. Adding the sub-routine of this program to the current circuit enables you to use [a day of the week] data of the specified year, month and day or the current day in the program. By combination with the system variable, LS[4]-[6], a weekly timer type of use is possible as described below and the application range is expanded.
1. For Lighting/Extinction time of illumination, Open/Close of a shutter etc. , Control of ON/OFF time every day of the week
2. Adding a day of the week when stored production data etc. are displayed on a screen and printed out.
3. Adding a day of the week when data in Logitouch are read out from PC etc.


Download a sample program file and detailed description.
